Printed Circuit Boards

  • September 1, 2022

Printed Circuit Board, also known as PCB, is a board that has conductive and insulating parts. PCB mechanically support and electrically connect the electronic components together. Solder is used to connect the electrical components on the surface of the PCB. It also acts a strong mechanical adhesive since solder is made of metal.

PCBs have different layers: Substrate, Copper, Soldermask, and Silkscreen layer:


Substrate: Any printed circuit board (PCB) will often have a substrate layer constructed out of fiberglass, which is what gives the board its firm structure. This material will make up the majority of boards' substrates, with the exception of flexible printed circuit boards (PCBs), which are constructed on flexible plastics like Kapton. In general, this material will make up the bulk of boards. Substrate PCB layers can also be created with other materials such as epoxies; however, these materials do not provide the same level of longevity for a high-grade board that FR4 (which can be found in fiberglass) can.

Copper: The next layer is a thin layer of copper foil, which is then laminated using heat. When we discuss the many distinct types of multilayer PCBs, we are talking to the number of copper layers that each board possesses. If you are making a single-sided printed circuit board (PCB), then the circuit board will only have one layer of conducting material on one side of the board. The opposite side of the board will be used for incorporating various electronic components. While single-sided PCBs can only place conductive copper and components on a single side of the board, double-sided PCBs can mount them on both sides of the board. Because the traces on these double-sided boards can alternate between the top and bottom layers utilizing vias, they make it possible to route them more closely. Because the circuits on one side of the board may be connected to the circuits on the other side of the board using the help of holes drilled into it, this can be highly beneficial in many different electronic goods.

Soldermask: Following the application of the copper layer, the soldermask layer is next placed on top. This is what gives the PCB its characteristic green color, and it is also used to isolate the copper layer so that it does not come into touch with any other metals or components of the board, which might cause the copper traces to get disrupted. This layer is also necessary for the manufacturing process that involves soldering the components onto the board. It does this by assisting the user in soldering to the appropriate locations on the board.

Silkscreen:  By adding letters, numbers, and symbols on the board, the silkscreen serves the primary aim of assisting humans in better comprehending the functionality of the board as a whole as well as the individual pins and LEDs that make up the board.


There are three common types of PCBs:


1. Rigid PCB: Rigid printed circuit boards (PCBs) are made from rigid fiberglass substrates, which gives them the advantages of being economical and practical but also makes them inflexible. They are far less versatile and difficult to fit into unique shapes or small places. However, they are much easier and less expensive to manufacture than their counterparts that are more flexible.

2. Flexible PCB: Flexible printed circuit boards have reasonably good bending and folding capabilities, which allow them to fit into spaces that are both limited and of an unusual shape. Because of this property, they have a great degree of versatility and can be utilized to package electronic equipment of a smaller size. In addition, because they are so versatile, the product does not need to be constructed in order to accommodate the limitations of the printed circuit board (PCB). They have the potential to offer superior heat resistance as compared to rigid PCBs.

3. Rigid-flex PCB: The most appealing aspects of rigid and flexible printed circuit boards (PCBs) are combined in rigid-flex PCBs. These printed circuit boards (PCBs), in contrast to the other two types of circuit boards, have all of the electronic interconnectivity concealed within the board itself. This helps to reduce the board's weight as well as its overall size. When the need for extremely lightweight packaging is paramount, they are a fantastic option to consider. In addition to this, they are more long-lasting and dependable while still maintaining an impressive level of strength and flexibility.


Frequently Asked Questions:


What is PCB and its layers?

A printed circuit board, also known as a printed wire board, is made up of layers of both conductive and insulating material that are laminated together. PCBs provide two purposes that are mutually beneficial. The first involves soldering electronic components to specific positions on the outer layers.

It is made up of Substrate, Copper, Soldermask, and Silkscreen layers.

What are the other types of Printed Circuit Boards (PCBs)?

The other types of PCBs are Single-sided PCB, Double-sided PCB, Multi-layered Rigid, Single-layer Flexible PCB, Double-sided Flexible PCB, Multi-layered Flexible PCB, High Frequency PCB, and Aluminum-back PCB

What industries benefit from the use of PCBs?

There are various benefits in the application of PCBs in different industries, such as medical, industrial and commercial, aerospace, and military. It is proven to be beneficial due to its durability, cost-efficiency, small-sized, lightweight, and its various use in different simple and complex systems.

Chip 1 Exchange offers a wide variation of Types of Printed Circuit Boards from multiple suppliers and manufacturers from different parts of the world. Our consumers are ensured with top-quality electronic components used for medical, automotive, industrial, mobile computing, and aerospace applications.

Chip 1 Exchange offers wide array of services to its consumers. We provide programs that aims to provide solutions to inventory management and reduction, efficient delivery and providing quality products to its customers to avoid delays in production, and design assistance and consultations with our experts.
