Electrical transformers are devices that consist of two or more coils of wire and are used to transfer electrical energy by means of a changing magnetic field. Changes in voltage and current are typically what take place throughout the process of energy transfer. AC voltage can be altered in either direction by using transformers. Transformers are utilized in almost all modern electrical systems.

How Transformers Function

Transformers do not produce electrical power; rather, they utilize magnetic coupling to move existing electrical power from one alternating current (AC) circuit to another. The windings, which are also referred to as coils, are what are known as windings in a transformer. The core of the transformer is there to provide a controlled channel for the magnetic flux that is generated inside the transformer by the current that flows through the windings. The fundamental transformer consists of four primary components in total. The Input Connection, the Output Connection, the Windings or Coils, and the Core are the components that make up this section.

Input Connections – This is called the primary side since the electrical power to be changed is connected to on this side.

Output Connections - The load is connected to the transformer's output side, also known as the secondary side. This is where the electrical power is delivered. The amount of incoming electric power can be either increased or decreased, and this is determined by the requirements of the load.

Winding - The primary winding and the secondary winding are the two types of windings that can be found in transformers. The winding that is responsible for drawing electricity from the source is called the primary winding. The secondary winding is the coil that is responsible for providing the load with the energy at the transformed or altered voltage. In order to lessen the amount of flux that is produced, these two coils are typically broken up into a few different coils.

Core - The magnetic flux that is produced inside the transformer needs a way to go in a directed manner, and the transformer core serves that purpose. In most cases, the core is not a single piece of solid steel but rather a building made up of numerous thin sheets or layers of steel that have been bonded together. This building is utilized to assist in the eradication of and reduction in heating.

Types of Transformers in Electronic Domain

Pulse Transformers - Pulse transformers are miniature transformers that are installed on printed circuit boards and are utilized in electrical devices to produce pulses with a predetermined amplitude. These transformers provide a digital load circuit with pulses of a constant amplitude while isolating it as a digital load.

Audio Transformers - It would be more accurate to categorize transformers used in the electronics industry according to the frequency range in which they are able to function. Audio transformers are a specific type of electronic transformer that can function at a frequency range that spans from 20 Hz all the way up to 20 kHz. These are typically utility transformers of a smaller size, and they have a laminated E-I core like the standard utility transformers that operate at 60 Hz. These transformers can either step up or step down in their output. Impedance matching is the primary function of an audio transformer, which is why these devices are engineered to have nearly no reactance. An audio transformer may contain a number of primary and secondary coils, each of which may be split apart from the other or center-tapped.

IF Transformers - In order to tune signals at an intermediate frequency, IF transformers are utilized. These are shielded transformers that typically have a high-permeability ferrite core in the center of the device.

RF Transformers - The electronic transformers that are used at radio frequencies are called RF transformers. These can be wire-wound transformers like utility transformers or can be transmission line transformers. The wire-wound transformers having a toroidal powdered-iron core are most common. Air-core RF transformers are used for high-power applications. While powdered-iron core transformers have high permeability and self-shielding, air-core transformers are much more energy-efficient, athough they have significant EMI. These transformers are also called broadband transformers and are used for a frequency range from 3 MHz to 30 MHz. At higher frequencies, transmission line transformers as quarter-wave antennas are used. These may be parallel-wire lines or coaxial cables.

Applications of Electronic Transformers

In the field of electronics, transformers are put to use for a variety of purposes, including the stepping up or down of voltages, the matching of impedances, the creation of pulses, coupling, and isolation.

The specifications of electronic transformers, including primary voltage, secondary voltage, and power rating, are typically printed on the transformers themselves. This is common practice in the field of electronics. In most cases, color schemes are utilized for the purpose of identifying the leads of the primary coil, the secondary winding, and the center tap.
