ISP1520BD ST-Ericsson | Chip 1 Exchange

ISP1520BD

Manufacturer: ST-Ericsson

Product Category: Microcontrollers and Processors

Description:

Product Technical Specifications

Manufacturer Part Number:

ISP1520BD

Part Life Cycle Code:

Obsolete

Ihs Manufacturer:

ST-ERICSSON

Part Package Code:

QFP

Package Description:

LFQFP, QFP64,.47SQ,20

Pin Count:

64

Reach Compliance Code:

unknown

HTS Code:

8542.31.00.01

Manufacturer:

ST-Ericsson

Risk Rank:

5.47

Clock Frequency-Max:

12 MHz

JESD-30 Code:

S-PQFP-G64

JESD-609 Code:

e3

Length:

10 mm

Moisture Sensitivity Level:

1

Number of Terminals:

64

Operating Temperature-Max:

70 °C

Operating Temperature-Min:

-40 °C

Package Body Material:

PLASTIC/EPOXY

Package Code:

LFQFP

Package Equivalence Code:

QFP64,.47SQ,20

Package Shape:

SQUARE

Package Style:

FLATPACK, LOW PROFILE, FINE PITCH

Peak Reflow Temperature (Cel):

260

Power Supplies:

3.3 V

Qualification Status:

Not Qualified

Seated Height-Max:

1.6 mm

Subcategory:

Bus Controllers

Supply Voltage-Max:

3.6 V

Supply Voltage-Min:

3 V

Supply Voltage-Nom:

3.3 V

Surface Mount:

YES

Technology:

CMOS

Temperature Grade:

OTHER

Terminal Finish:

MATTE TIN

Terminal Form:

GULL WING

Terminal Pitch:

0.5 mm

Terminal Position:

QUAD

Time@Peak Reflow Temperature-Max (s):

30

Width:

10 mm

uPs/uCs/Peripheral ICs Type:

BUS CONTROLLER, UNIVERSAL SERIAL BUS

Fast Shipping

Alternate Parts

ISP1520BDGA
